TES-1885U-D1521-8GR

TES-1885U-D1521-8GR
CPU | Intel® Xeon® Processor D-1521, 4-core 2.4 GHz |
システムメモリ | Total DIMM slots: 4 Maximum memory: DDR4 128 GB ( 32 GB RDIMM x 4 ) Memory modules pre-installed: TES-1885U-D1521-8GR: 8 GB ECC RAM ( 8 GB RDIMM x 1 ) Note: TES-1885U requires at least 32GB RAM for running QES operating system. |
フラッシュメモリ | 4 GB DOM |
ドライブベイ | Front: 2.5″ / 3.5″ x 12 Rear: 2.5″ SSD slot x 6 |
ドライブの互換性 | Front: SAS 12Gb/s, SAS 6Gb/s, SATA 6Gb/s HDD and SSD Rear: SATA 6Gb/s SSD |
USBポート | 2 x USB 3.0 port (rear)
For QTS OS: The USB slots support pen drives and other USB-ready devices such as printers, UPS, etc. |
ギガビットイーサネットポート | 2 x SFP+ 10GbE ports, 4 x Gigabit ports |
LEDインジケーター | 10 GbE, Status, LAN, Storage expansion port status |
ボタン | System: Power button and reset button |
フォームファクター | 2U, Rackmount |
寸法(H x W x D) | 88 x 442.5 x 530.5 mm 3.46 x 17.42 x 20.89 inch |
重量 | Net weight (NAS only): 15.34 kg (33.82 lbs) Gross weight (with packing and accessories): 21.25 kg (46.85 lbs) |
動作温度と相対湿度 | 0-40˚C, 5~95% non-condensing, wet bulb: 27˚C. |
電力消費量(W) | In Operation: 229.53W |
電源装置 | Redundant power: Input 90~264VAC; 450W x 2 |
PCIeスロット | Number: 4 Slot 1: PCIe Gen.3 x8Slot 2: PCIe Gen.2 x4 Slot 3: PCIe Gen.3 x4 Slot 4: PCIe Gen.3 x4 or PCIe Gen.3 x8 Note: Slot 4 provides the width of PCIe Gen.3 x8 when slot 3 is not in use. Slot 4 then provides the width of PCIe Gen.3 x4 only when an expansion board is installed in slot 3. |
ファン | 4 x 6 cm smart cooling fan |
Note: Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications. Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.
* Sound Level Test Environment: Refer to ISO 7779; Maximum HDD loaded; Bystander Position; Average data from 1 meter in front of operating NAS.
Designs and specifications are subject to change without notice.
* Sound Level Test Environment: Refer to ISO 7779; Maximum HDD loaded; Bystander Position; Average data from 1 meter in front of operating NAS.
Designs and specifications are subject to change without notice.
SASディスクの種類 | ||||||
---|---|---|---|---|---|---|
カテゴリ | 説明 | 回転数 | 回転振動対策 | 適用Bay数 | 稼働時間 | 信頼性(MTBF) |
カテゴリNL-SAS | 説明インターフェース速度12Gbps(SAS)の耐障害性に優れたニアラインSAS | 回転数7200rpm | 回転振動対策◎ | 適用Bay数1-24bay | 稼働時間24x365 常時稼働可 |
信頼性(MTBF)◎ (140-200万時間) |
SATAディスクの種類 | ||||||
カテゴリ | 説明 | 回転数 | 回転振動対策 | 適用Bay数 | 稼働時間 | 信頼性(MTBF) |
カテゴリNL-SATA | 説明ニアラインSASのSATAインタフェースモデル SATAの最上位グレード、高頻度書き込みに対応 |
回転数7200rpm | 回転振動対策◎ | 適用Bay数1-24bay | 稼働時間24x365 常時稼働可 |
信頼性(MTBF)◎ (140-200万時間) |
カテゴリEnterprise-SATA | 説明NAS向けの設計でコスト性能比が高く、ラックマウントにおすすめのモデル | 回転数7200rpm | 回転振動対策○ | 適用Bay数1-16bay | 稼働時間24x365 常時稼働可 |
信頼性(MTBF)○ (100-120万時間) |
カテゴリNAS-SATA | 説明NAS向けの設計。低価格でラックマウントのエントリモデルやデスクトップに適したモデル。 | 回転数5900~7200rpm | 回転振動対策- | 適用Bay数1-8bay | 稼働時間24x365 常時稼働可 |
信頼性(MTBF)○ (80-100万時間) |
SSDの種類 | ||||||
カテゴリ | 説明 | 回転数 | 回転振動対策 | 適用Bay数 | 稼働時間 | 信頼性(MTBF) |
カテゴリミドルクラスSSD | 説明フラッシュメモリによる超高速、低消費電力で稼働するSSD。ノートPC等に搭載されているSSDよりワンランク上の信頼性とパフォーマンス。 | 回転数- | 回転振動対策- | 適用Bay数制限なし | 稼働時間24x365 常時稼働可 |
信頼性(MTBF)◎ |
